Overview


4000RA Series Concealed Mount, Medium Duty Overhead Holder & Stop, Adjustable

  • Concealed Mount
  • Medium Duty
  • Internal channel slide allows for adjustable degree of opening in field
  • Stop, hold-open and friction functions available
  • Single or double acting doors
  • Non-handed
  • For interior or exterior use on moderate traffic and medium weight doors
  • Standard installation from 85° to 110° (5° increments)
  • Shock absorbing spring provides 3° to 5° cuhsion before dead-stop
  • 1-3/8" minimum door thickness
  • UL Listed as Miscellaneous Fire Door Accessories for use on wood fire doors rated up to 90 minutes and metal fire doors rated up to 3 hours (stop function only)
  • Average weight per unit = 2 lbs


See More


Specifications

Finishes
US32D - 630 - Satin Stainless SteelUS10 - 612 - Satin BronzeUS10B - 613 - Oil Rubbed Bronze
US26D - 626 - Satin ChromeUS4 - 606 - Satin BrassUS26 - 625 - Bright Chrome
US3 - 605 - Bright BrassUS32 - 629 - Bright Stainless SteelS1 - 689 - Painted Aluminum
S2 - Painted Brass (to match US4)S3 - Painted Bronze (to match US10)S4 - Painted Black
S5 - Painted Dark Bronze (to match US10B)S8 - Painted White
