ABH Manufacturing -3400 Series Surface Mount Overhead Stop & Holder

DOWNLOADS

  • Surface Mount
  • Medium Duty
  • Side jamb mount for doors that do not extend to frame header
  • Ideal for dressing room and washroom stall doors with frames
  • Stop, hold-open and friction functions available
  • Single acting doors only


Category: door hold open devices | door holders | door stops...

MasterFormat: Doors and Frames | Hardware | Door Hardware



ABH Manufacturing
1222 Ardmore Ave.
Itasca, IL 60143
Tel: (630) 875-9900
Fax: (800) 932-9224

abhinfo@abhmfg.com

https://www.abhmfg.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


3400 Series Surface Mount Overhead Stop & Holder

  • Surface Mount
  • Medium Duty
  • Side jamb mount for doors that do not extend to frame header
  • Ideal for dressing room and washroom stall doors with frames
  • Stop, hold-open and friction functions available
  • Single acting doors only
  • Non-handed
  • Standard installation from 90° to 100° of opening (5° increments)
  • Shock absorbing spring provides 3° to 5° cushion before dead-stop
  • Standard fasteners supplied with sex bolts for 1-3/4" to 1-7/8" thick door (see options for other door thickness)
  • Average weight per unit = 3 lbs.


See More


Specifications

Finishes
US32D - 630 - Satin Stainless SteelUS10 - 612 - Satin BronzeUS10B - 613 - Oil Rubbed Bronze
US26D - 626 - Satin ChromeUS4 - 606 - Satin BrassUS26 - 625 - Bright Chrome
US3 - 605 - Bright BrassUS32 - 629 - Bright Stainless SteelS1 - 689 - Painted Aluminum
S2 - Painted Brass (to match US4)S3 - Painted Bronze (to match US10)S4 - Painted Black
S5 - Painted Dark Bronze (to match US10B)S8 - Painted White
