Overview


1000SA Series Concealed Mount Overhead Stop & Holder

  • Concealed Mount
  • Heavy Duty
  • Slime line channel designed for aluminum store front doors
  • Stop and hold-open functions avialable
  • Single or double acting doors
  • Non-handed
  • For Interior or exterior use on frequent traffic and heavy weight doors
  • Degree of opening is field adjustable from 85° to 110° (5° increments)
  • Shock absorbing spring provides 3° to 5° cushion before dead-stop
  • 1 3/4” minimum door thickness
  • UL Listed as Miscellaneous Fire Door Accessories for use on wood fire doors rated up to 90 minutes and metal fire doors rated up to3 hours (stop function only)
  • Average weight per unit = 5 lbs.


See More


Specifications

Finishes
US32D - 630 - Satin Stainless SteelUS10 - 612 - Satin BronzeUS10B - 613 - Oil Rubbed Bronze
US26D - 626 - Satin ChromeUS4 - 606 - Satin BrassUS26 - 625 - Bright Chrome
US3 - 605 - Bright BrassUS32 - 629 - Bright Stainless SteelS1 - 689 - Painted Aluminum
S2 - Painted Brass (to match US4)S3 - Painted Bronze (to match US10)S4 - Painted Black
S5 - Painted Dark Bronze (to match US10B)S8 - Painted White
