- Operating sash tilt in for glass cleaning
from interior
- Flexible PVC gasket is reusable
for glass replacement
- Hardware is replaced, if necessary,
withstandard tools
|
|
- Tilt latches are spring-loaded for
automatic engagement
- Sash removal is restricted with
pivot barsnap locks
- Tilt latches are concealed in sash
to resist tampering
|
|
- 1" insulating glass in channel
gasket glazing
- Meeting rail locks
(not available with dual glazed option)
- AAMA Class 2 spiral balances and
spring-loaded tilt latches
|
|
- Single glazed - maximum 1/4". Dual glazed
(split sash) -maximum 1/4"
- AAMA Class 2 block & tackle balances
- AAMA Class 5 heavy duty spring
balances (standard for TR-9000 AW)
- Three-lite window (one top fixed
and two operating sash- all in one frame)
- Head and sill automatic locks (standard
with dual glazed)
- Oriel (unequal) sash (specify
sill-to-CMR dimension)
- Full protection, half insect, or full insect
exterior screens
- Flange frame; exterior or internal muntins
|
