LP® SolidStart® Rim Board

Manufactured for strength and consistency, our rim board products are precision cut to work perfectly with our LP SolidStart I-Joists and LVL and LSL beams. That makes them ideal for supporting vertical and lateral wall loads as part of a floor system. Options include rim board manufactured from LSL, LVL or OSB in a wide range of depths and thicknesses. LP SolidStart Rim Board speeds construction by eliminating the need for field-ripping and creating flat surfaces for siding installation. High load capacity eliminates the need for squash blocks in most multi-story application.

Benefits
  • Easy to saw, drill, plane, file or sand with normal carpentry tools
  • I-Joist compatible depths save time on the job-site
  • Pre-cut depths mean less inaccuracies and time involved in ripping in the field
  • High load capacity
  • Lifetime Limited Warranty
  • SFI-Certified

Rim Board Quick Reference

Product

Thickness

Depths

Standard Lengths

LP SolidStart OSB Rim Board

1', 1-1/8'

9-1/2', 11-7/8', 14', 16', 18', 20', 22', and 24'

12', 16'

LP SolidStart LVL Rim Board

1-1/4'

9-1/2', 11-7/8', 14', 16', 18', 20', 22', and 24'

12', 16'

LP SolidStart LSL Rim Board

1-1/4', 1-1/2'

9-1/2', 11-7/8', 14', 16', 18', 20', 22', and 24'

12', 16'

Note: Material Safety Data Sheets (MSDS) are available online at www.lpcorp.com or by contacting customer support at 1.888/820.0325.
