EDX4 is a continuous edge grip dry seal aluminum composite cladding system. Like RDX, this system is suitable for use on wall cladding applications where a dry joint is desired. The EDX4 edge grip system is particularly useful on curved applications and for applications where panel module sizes don't economically allow for return legs.
- Dry Seal System (no field sealant of panel joints)
- Continuous attachment systems eliminates need for horizontal sub-framing
- Excellent for dry seal curved applications
- Efficient ACM usage with 30" panel modules
- Meets ASTM standards for water & air infiltration and wind loading
- Wall Cladding
- Soffit Cladding
- Fascias
- Screen Walls
- High Performance Paint
- Anodized
- Brushed Aluminum
- Zinc
- Stainless Steel
- Copper
- 4mm Aluminum Composite Material
- System Depth = 1 ½”
- Panel Joint Width = ½”
- Maximum Panel Height = 32”
- Minimum Panel Height = 3”
- Maximum Panel Length = 240”
- Minimum Panel Length = 12”
