2" ThermaStile™ Aluminum Swing Entrance Doors

Series D202 (TS) • Series D302 (TS) • Series D502 (TS)

EFCO ThermaStile entrance doors are designed to meet applications where security, egress, thermal performance and dual finish capability is required. ThermaStile doors are joint plug welded at each corner to provide superior strength in all applications. Offered in narrow, medium and wide stiles, ThermaStile doors accommodate a wide range of applications. Also, multiple glazing options provide flexibility to meet specific design requirements. The ability to accommodate most hardware applications increases the versatility of this product. ThermaStile entrances are thermally improved, enhancing energy saving potential. EFCO ThermaStile entrance doors provide the complete solution for your fenestration needs.

Model

• D202 Narrow Stile Thermal Doors
• D302 Medium Stile Thermal Doors
• D502 Wide Stile Thermal Doors

Feature

• E-Strut™ Thermal isolator
• Exterior corners are true mortise and tenon
• Interior corners are joined by concealed reinforcement brackets and deep penetration fillet weld
• Accepts most major brands of locking hardware, panic devices, Rixson HD pivots and continuous hinges. Butt hinges are not used on these doors
• Accommodates all surface mounted, concealed overhead and floor closers
• Tall bottom rails available
• Variety of cross rails, door sweeps, and crash bars available
• Anodized and painted finishes available

Benefit

• Dual finish capability
• Physical interlock between the rails and stiles increases strength of door
• Improves ability to function correctly in high-usage applications
• Able to comply with special hardware specifications
• Unrestricted closer choices
• Meets ADA requirements
• Increases configuration options
• Unlimited options to answer economic and aesthetic concerns
