PRODUCT PRESENTATION
Englert Series 2500 is a variable width (12" - 18" wide) 2" high structural panel system, with optional ribs. The variable width feature allows you to specify whichever width works with your structural design parameters and exterior aesthetics (12", 15", 16" or 18").

Englert Series 2500 Roofing System is secured by a uniquely designed clip that allows for thermal expansion/contraction of the panel system. The panels are seamed by an electric seamer and are designed with a sealant, which gives added protection on low slopes.

MATERIALS & FINISHES
24 ga. Galvalume conforming to ASTM A-792, AZ-55, 50 KSI yield point or 22 ga. Galvalume, 50 KSI or .032" and .040" aluminum alloy 3105-H14 or equal with baked on PermaColor 2000 in Kynar 500®/Hylar 5000® in all standard colors or PermaMetallic 2000 metallic coatings in a smooth finish. (See manufacturer for Color Card and Coating & Finish Processes.)

FLASHING & FLAT STOCK
All exposed flashing to be field formed in the same gauge, finish, color and texture as the panels. Protective strippable film should be removed at the time of the installation.

USES & APPLICATIONS
As an integrated roofing system, Englert Series 2500 Panel System may be installed over a 16 ga. purlins, or solid deck with 2 layers of 15# felt or 1 layer of 30# felt. Englert Series 2500 Roofing System may also be installed over metal deck and rigid insulation with bearing plates, with 1 layer of 30# felt or 2 layers of 15# felt. Pitch criteria is a minimum slope of 1/4"/12" or greater for panels up to 75' long; 1/2"/12" for panel lengths up to 100'; 1"/12" slope on panel lengths over 100' up to 150'.

Do not install panels directly over chemically treated wood. Panels should be continuous from ridge to eave with no end laps. Horizontal purlins, 2 x 4’s, plywood or metal decking under the Series 2500 system should be true, plumb and straight. Any deflection may cause panels to oil can. Such oil canning is not a cause for product refusal.

SPECIFICATIONS
NOTE TO SPECIFIER: Englert Series 2500 Panel System serves the structural needs of roofing/fascia and mansard systems.

The Series 2500 may be specified for application over solid deck or over purlins or over metal deck with rigid insulation. The Series 2500 Panel System can also be secured with bearing plates and clips through the insulation to the metal deck. Minimum Pitch: 1/2"/12". Specify as required.

A. Panel System shall be the Englert Series 2500, 2" high, 16" wide, Structural Standing Seam System (with ribs). Mechanical seaming available in 45 degree. The panels shall have baked on finish as specified in "Materials & Finishes," in manufacturer’s standard colors. Manufacturer shall offer a minimum of 23 standard colors to choose from.

B. Substrate
- 24 gauge baked on finish over Galvalume ASTM A-792-83, AZ-55, 40 KSI yield point, 52 KSI tensile strength.
- * 22 gauge baked on finish over Galvalume per ASTM A-792-83, AZ-55, 40 KSI yield point, 52 KSI tensile strength.
- * .032" or .040" Aluminum Alloy 3105-HI4 approved equal.
* NOTE TO SPECIFIER: 22 gauge steel and .032" and .040" aluminum are available subject to minimum order requirements. Call Englert for details.

C. Performance
1. Panel shall meet the requirements of Underwriters Laboratories, Inc. for Class 90 wind uplift resistance.
2. ASTM E-283-84 air infiltration: Maximum of 0.006 CFM/Ft² at 1.57 PSF pressure differential on 45 degree seamed profile and 0.013 CFM/Ft² at 6.24 PSF pressure differential.
3. ASTM E-331-70 water penetration: No evidence of uncontrolled leakage on 45 degree seamed panel at 15.10 PSF pressure differential.
4. Panel shall display a flame spread classification of a Class 1, when tested in accordance with ASTM E-84-87.
5. Panel shall have been tested and rated in accordance with ASTM E-1592 structural performance of sheet metal roof and siding systems by uniform static air pressure difference.
NOTE TO SPECIFIER: Series 2500 Panels @ 2" x 16" wide in 24 gauge Galvalume meet the Underwriters Laboratories 580 classification when installed over purlins at 5' to 0" o.c. with special clips. UL Listings available upon request.
