Paddock Stainless Steel Recirculating Perimeters

Basics:

Selected Models:

For Competition
The C300 three-channel perimeter is a high capacity system designed to control dynamic surge through the use of an integrated Auxiliary Surge Recovery (“ASR”) chamber. Excess water in the overflow channel is drawn by positive suction into the covered ASR chamber when triggered by an automatic level sensor and returned immediately to the pool. The C300 insures that the water level is maintained at the rim, minimizes rebound of waves off the pool wall, and prevents the gutter from ever flooding. The result is the smoothest, fastest water surface for competition pools, and the most pleasant experience possible for swimmers using the pool for recreation.

The C300 offers an optional removable tile insert installed in the face of the perimeter to match a tiled pool interior or deck, and to provide a textured surface for flip turns.

All the standard Paddock features are included with the C300: jet wash fittings to enhance recirculation and prevent algae growth, protective PVC grating with 32% open area, nylon inlet nozzles, slip resistant surfaces, and surge weirs (if desired).

Paddock Stainless Steel Recirculating Perimeters

For Recreation
Paddock’s R300 perimeter combines the aesthetic benefits of free form design with the practicality of the “pipeless” stainless steel recirculation system introduced by Paddock over 40 years ago. Inverse corners can now be made smooth, and creative flourishes such as rounded stair entries, zero depth areas, and spas can be added to traditional pools for enhanced appearance and wide appeal to a variety of users. The spacious overflow channel and high capacity filtered water return tube make the R300 the perfect choice for wave pools, plunge pools, lazy rivers, and heavy-use recreation pools of all sizes and shapes.

The R300 perimeter is a unique application of proven engineering that provides superior performance without restricting creative possibilities, and the R300-T goes one step farther—the addition of tile brings a splash of color to an already striking design.
