Thin Brick

Thin Brick meet ASTM C 1088-09 standard specification for Thin Veneer Brick Units made from clay or shale. In this specification, the term thin veneer brick shall be understood to mean clay masonry unit with a maximum thickness of 1-3/4".

Grade Exterior: Belden Brick manufactures thin brick to meet Grade Exterior with a weathering index of SW.

Type TBS (Standard) – Thin veneer brick for general use in masonry.

Type TBX (Select) – Thin veneer brick for use in general masonry where a higher degree of precision and lower permissible variation in size than permitted for Type TBS is required.

Type TBA (Architectural) – Thin veneer brick for general use in masonry selected to produce characteristic architectural effects resulting from non-uniformity in size and texture of the individual units.

Manufactured to Meet Type TBX. Available in 1/2" to 3/4"Flat Back Units and 3/4" only for Dovetail Units. Dovetail units have 5/8" shell thickness plus 1/8" dovetail = 3/4" overall thickness.

Capabilities to manufacture units up to 4" in height & 12" in length. Includes 12 different sizes ranging from Modular(2-1/4" × 7-5/8") to Utility (3-5/8" × 11-5/8").

Specify Units with Smooth & Velour Textures for Best Economics.
Some heavily textured products such as matt, vertical, bark & dart-tex textures available on a per job basis.

• Waxing of Unit Faces Available for Stretchers & Corners
• Grinding of Units Also Available for Length & Height
• Dimensional Tolerances of Plus 0 / Minus 1/16th"

Manufactured to Meet Type TBA and available in 3/4" Flat Back Units only.

Plant 3 – Antique Colonials

• Modular 2-1/4" × 7-5/8"
• Jumbo Standard 2-5/8" × 8"

Plant 8 – Belcrest

• Modular 2-1/4" × 7-5/8"

Thickness: 3/4"
