The CENTRIA IW Series of panels combines concealed fasteners
with a wide range of design options for field assembled wall systems. Available
in a broad selection of profiles, these panels are designed with a lock-joint
system which produces a weather resistant wall that has an aesthetically pleasing
"monolithic" appearance.
Concealed fastener field assembled panel systems are available for insulated or
uninsulated applications. When insulated, the panel includes an exterior profile
and an interior liner. Features of these panel systems include:
- No exposed fasteners, provide clean, unbroken profiles at an affordable cost
- Strong steel panels permit designs for various span requirements
- Interchangeable panels (except IW-60A), due to the common lock-joint design,
permit many interesting visual effects
- All-weather installation capability shortens installation time and permits
fast-track scheduling
- Stucco-embossed or smooth finishes in flush, vertically ribbed, striated,
and stepped profiles help designers achieve reveals and shadows, visual textures,
and other distinctive architectural effects
- Lengths to 30'-0" with quick delivery
- Vertical applications for all profiles. IW 60A may be installed horizontally
or vertically.
- Horizontal applications for IW-10A, IW-11A, IW-13A, IW-14A, IW-40A, IW-41A
and IW-60A. Liner panel back up is provided for all but IW-60A.
For accessory products and design options, see the “Profile Series
Design Options” Profile.
- Standard 24-18 gage G-90 galvanized steel
- Galvalume® steel aluminum or stainless steel optional
- Smooth or Embossed surface texture
- Lock joint design of IW10A-IW41A
|
