Tectum: A Unique Acoustical Product

Tectum Acoustical Products

Tectum Interior Panels offer an effective, permanent and attractive solution for any kind of activity that produces undesirable noise levels within an enclosed space. They are abuse-resistant and are able to withstand the impact of thrown or kicked balls in gyms, yet are lightweight.

Tectum acoustical panels are easy to install in new construction and in existing buildings for effective sound control. Up to 1.00 NRC can be achieved. Panels are typically screwed to furring strips installed 24" o.c. horizontally (when using vertical panels). Panels can be screwed directly to masonry, block or wood substrates.

LEED Contribution/Environmental Statement

Tectum Inc. fully endorses the LEED Green Building Rating System. A number of our representatives are LEED-accredited professionals and members of local USGBC chapters.

Tectum panels are made from sustainable domestic, renewable raw materials. The wood is harvested from new forest growth that reaches maturity in 15 – 20 years. Tectum Inc. only purchases excelsior from companies that are part of the Sustainable Forestry Initiative (SFI).

Our products may contribute to the following LEED credit areas:

• EA Prerequisite 2: Fundamental Energy Performance
• EA Credit 1: Optimized Energy Performance
• MR Credits 2.1 and 2.2: Construction Site Waste Management
• MR Credits 4.1 and 4.2: Recycled Content
• MR Credit 7: Certified Wood
• EQ Prerequisite 3: Minimum Acoustical Performance
• EQ Credit 3.1 and 3.2: Construction IAQ Plans
• EQ Credit 4.1: Low-Emitting Materials, Adhesives and Sealants
• EQ Credit 4.4: Low-Emitting Materials, Composite Wood & Agrifiber Products
• EQ 10: Mold Prevention (LEED for Schools)
• EQ Credit 11: Low-Impact Cleaning and Maintenance Equipment Policy (LEED for Schools)
• ID 1 – 1.4: Innovation in Design

For complete information about Tectum products and LEED, please see our Marketing Bulletin M-81 (Tectum Products and LEED Certification) or our Environmental Statement. All of these materials are available online at www.tectum.com.

*Note: Tectum is a registered trademark of Tectum Inc.

• New York City Board of Standards and Appeals. Calendar No. 391-52-SM.
• Corp of Engineers Guide: Specification CE-219.01.
• Southern Building Code Congress Report No. 9406B.
• ICC-ES Evaluation Report: ESR-1112
• Building Officials Conference of America. BOCA 86-39.
• Los Angeles Research Report: RR 25165
• State of CA DSA number PA-008.
• Complies with ASTM E1264, Type XIV, Pattern L, Class A.
• Underwriters Laboratories Canada label.

Tectum acoustical panels can be used over swimming pools and in open construction such as breezeways and open garages. However, they should not be installed where they will come in direct contact with water or condensation. Reveal edge panels (Tonico or Multi-Plane) should not be used for these purposes.

1" panels 23 3/4" x 47 3/4" size should not be used where the relative humidity will exceed 85%. Panels 1 1/2" or thicker are not restricted by humidity conditions.

In all cases, the plenum must provide cross-ventilation to prevent condensation. The ventilation recommendation of the current edition of the ASHRAE Handbook of Fundamentals and Guide and Data Book should be followed.

Tectum ceiling and wall panel width and length are ± 1/8", and over 4' lengths, + 1/8", - 1/4". Thickness is nominal. Panels that are to be butted must be beveled and will require field fitting. (Or molding can be used to cover edges.)

Tectum Inc. assumes full responsibility for its products and systems when installed in accordance with Tectum Inc.'s published recommendations at the time of purchase. Liability is limited to a refund of the purchase price or replacement of the material. Tectum Inc. will not be responsible for any labor or other charges for replacement of installation of defective material that has been shipped and/or installed, regardless of the circumstances.

All installations should be in accordance with the Ceiling & Interior Systems Construction Association's Code of Practices.

*Refer to Marketing Bulletin M-40, available at www.tectum.com for additional information.

Installation of Tectum panels consists of furnishing all labor, materials, accessories and equipment necessary to cover all areas shown on the drawings and specified herein.

The acoustical contractor shall furnish all labor, materials and equipment necessary for the complete acoustical installation as shown in the drawings and as specified.

Store this product in a dry place. Do not place in contact with the floors or walls. Ceiling panel packages must be protected against marring, soil or damage during storage and erection. Cover the bottom of tiles with moisture-proof materials and allow for circulation under cover to prevent condensation.

WARNING: Tectum acoustical panels are interior acoustical products and, as all other interior acoustical products, must not be subjected to water.

The building in which the Tectum panels are to be erected should be closed in and conditioned in cold seasons. Heating should be in operation prior to installation.

Materials should be located at the jobsite for at least 24 hours prior to application so that they can adjust to bring temperature and moisture into equilibrium.

Panels are not recommended for installation where they can come into contact with free water.

• Tectum wall panel edges should always be beveled on the long side.
• Use 8' panels or shorter when three or more panels are butted end to end.
• The butting of end joints will require field cutting to ensure proper alignment.
• Reveal edge panels (Tonico or Multi-plane) should not be used in areas where high humidity exists.
• Refer to Technical Bulletin T-60 on www.tectum.com for complete wall panel installation instructions.
• At minimum, 1 1/2" panels are recommended for protected exterior applications.

Additional technical information and design details on the use of Tectum panels are available and may be obtained by contacting Tectum Inc.
