When protection is a primary concern, count on high-performance
Saflex® interlayer for laminated glass.
Exceptional protection for the world's most significant structures.
From I.M. Pei's glass pyramid at the Louvre to Richard Meier's Getty Museum.
From the glass that protects the Mona Lisa to the glass that safeguards America's
Declaration of Independence. Time after time, laminated glass made with Saflex
protective interlayer was the trusted choice. Saflex is a protective polyvinyl
butyral (PVB) plastic based interlayer so tough and resilient, it is recognized
as the world's leading brand.
THE MANY BENEFITS OF SAFLEX PROTECTIVE INTERLAYERS FOR LAMINATED GLASS
Safety The toughness and resiliency of laminated glass makes it an excellent safety glazing. When laminated glass with Saflex protective interlayer is used in glazing design, the risk of injury as a result of flying or falling glass is considerably reduced. (See Profile 5)
Security The remarkable strengths of Saflex protective interlayer resists damage from forced entry or bomb blasts. While glass made with Saflex interlayer may crack from an impact, it won't shatter because the fragments tend to adhere to the protective interlayer. (See Profile 5)
Sound Control The acoustical dampening performance of the interlayer makes laminated glass an effective sound control product. The Saflex interlayer is highly effective in dampening transmitted sounds like those from airplanes, traffic, trains and heavy machinery. (See Profile 6)
Acoustical Rating
| Type of Glazing |
|
|
| Single Strength Monolithic |
|
|
| Double Strength Monolithic |
|
|
| Insulating Unit-Monolithic Lites1 |
|
|
| Saflex Laminated Glass2 |
|
|
| Saflex Laminated Insulating Unit3 |
|
|
Nominal Panel Size: 34" x 76". Test Temperature approximately 70
degrees F.
1 Insulating units: 1 inch overall.
2 Saflex Laminated glass 1/8-inch glass {0.060-inch Saflex
interlayer} 1/8-inch glass.
3 Saflex Laminated Insulating Unit 1/8-inch glass {0.030-inch
Saflex interlayer} 1/8-inch glass [1/2-inch airspace]
1/4-inch glass.
* Sound Transmission Class
** Outdoor/Indoor Transmission Class
Storm Protection Saflex HP and Saflex, in specified configurations, are impact-resistant glass products that can be a critical first line of defense against hurricanes, typhoons and violent storms. Glazing systems made with Saflex HP meet the stringent requirements of wind debris codes and standards. (See Profile 7)
Earthtone and Skytone Color Options With Saflex brand interlayers, color can be added to enhance any project while taking advantage of all of its protective benefits. Saflex can match the colors of glazing tints and films. All while screening out up to 99 percent of damaging UV light, controlling glare and decreasing solar energy transmittance. (See Table II for Saflex Laminated Glass Heat and Light Control Characteristics, see Profile 8 for Color details)
Exceptional Protection Comes with Exceptional Service
Solutia recognizes that the creativity and performance requirements of architects are dynamic. Solutia is committed to meeting the evolving needs of architects and designers by continuing to develop and bring new products to market. The Solutia offerings allow architects and designers to use glass in applications never before thought possible.
The Solutia Architectural Glazing Solutions Centre (AGSC) provides a comprehensive range of services to support architects and designers. The AGSC can provide technical support, literature, master specs, testing data and samples, as well as laminator and window manufacturer referrals. The AGSC also offers AIA CEU courses.
Discover how Saflex protective interlayer for laminated glass can help you design with freedom and performance. Contact the AGSC at 1-877-674-1233, www.saflex.com or glazin@solutia.com for a customized architectural solution.
Saflex Protective Interlayers
Preferred Listing of Manufacturers of Laminated
Architectural Glass
Architectural Safety Glass
7337 Commercial Circle
Ft. Pierce, FL 34951
T: (561) 467-0006
F: (561) 467-0660
Arch Aluminum & Glass
W226 N758 Eastmound Dr.
Waukesha, WI 53186
T: (262) 544-9095
F: (262) 544-4018
California Glass Bending Co.
320 E. Harry Bridges Blvd.
Wilmington, CA 90744
T: (800) 223-6594
F: (310) 549-5398
Cardinal LG
250 Griffin Street East
Amery, WI 54001
T: (715) 268-8111
F: (715) 268-8202
e-mail:
sales@AMLG.Cardinalcorp.com
DEPP Glass
41-40 38th Street
Long Island City, NY 11101
T: (718) 784-8500
F: (718) 784-9018
Dlubak Corporation
P.O. Box 510
520 Chestnut St.
Blairsville, PA 15717
T: (724) 459-9540
F: (724) 459 -0866
Floral Glass & Mirror Inc.
895 Motor Parkway
Hauppauge, NY 11788
T: (631) 234-2200
F: (631) 234-8866
e-mail: info@floralglass.com
Glass Pro Inc.
9401 Ann St.
Santa Fe Springs, CA 90670
T: (800) 776-2368
F: (562) 946-2764
Glass Products Inc.
Clidco Drive
P.O. Box 313
Carbondale, PA 18407
T: (570) 282-6711
F: (570) 282-1382
Globe Amerada Architectural Glass Co.
616 Selfield Road
Selma, Alabama 36703
T: (334) 875-1900
F: (334) 875-2704
e-mail: globeamerada@worldnet.att.net
Guardian Canada
355 Attwell Drive
Rexdale, Ontario
M9W 5C2 Canada
T: (416) 674-6945
F: (416) 674-8576
Guardian Lewistown
One Belle Ave. (Building 35)
Lewistown, PA 17044
T: (717) 242-2571
F: (717) 242-0450
Guardian Reedley
1485 E. Curtis Ave.
Reedley, CA 93654
T: (559) 638-3588
F: (559) 638-9758
Hehr Glass International
1021 Walnut Ave.
Pomona, CA 91766
T: (909) 628-5557
F: (909) 613-0857
Oldcastle Glass Inc.-Houston
1331 W. Sam Houston
Parkway North
Houston, TX 77043
T: (713) 464-5611
F: (713) 464-9313
Oldcastle Glass Inc.-Tampa
5115 E. Hartford St.
Tampa, FL 33619
T: (813) 247-3184
F: (813) 248-1861
Interpane Glass Company
P.O. Box 408
520 East Railroad St.
Clinton, NC 28328
T: (910) 592-7101
F: (910) 592-7266
e-mail: service@interpane.com
Lami Glass
20350 Langley Bypass
No. 10 Highway
Langley, British Columbia
V3A 5E7 Canada
T: (604) 530-9333
F: (604) 530-8870
Oldcastle Glass Inc. - Telford
375 E. Church Ave.
Telford, PA 18969-1003
T: (215) 721-0400
F: (215) 721-0402
e-mail: lgcsales@laminatedglass.com
Lamiver Inc.
3805 rue Dollard Desjardins
Montreal, Quebec
H1B 5W9 Canada
T: (514) 640-6490
F: (514) 640-6497
Mirror Factory Inc.
12725 16th Ave. North
Plymouth, MN 55441
T: (612) 557-1155
National Glass Ltd.
5744 198th St.
Langley, British Columbia
V3A 7J2 Canada
T: (604) 530-2311
F: (604) 530-4662
Northwestern Industries Inc.
2500 W. Jameson
Seattle, WA 98199
T: (206) 285-3140
F: (206) 285-3603
Prelco Inc.
94 Cartier Blvd.
Riviere-Du-Loup
Quebec, Canada G5R 2M9
T: (418) 862-2274
F: (418) 862-8181
Standard Bent Glass Inc.
P.O. Box 469
Butler, PA 16003-0469
T: (724) 287-3747
F: (724) 283-9836
e-mail: sbg@nauticom.net
Sully-North America
2175 Kumry Road
P.O. Box 70
Trumbauersville, PA 18970-0070
T: (215) 536-0333
F: (215) 536-2025
Oldcastle Glass Inc. - Miami
17851 N.W Miami Ct.
Miami, FL 33169
T: (305) 652-3380
F: (305) 652-3369
Oldcastle Glass Inc. - Perrysburg
291 "M" St. (Ampoint)
Perrysburg, OH 43551
T: (419) 666-2000
F: (419) 661-5076
Oldcastle Glass Inc. - Grand Prarie
1101 Fountain Parkway
Grand Prairie, TX 75050
T: (972) 647-4028
F: (972) 647-2439
Oldcastle Glass Inc. - Freemont
48999 Kato Road
Fremont, CA 94539
T: (510) 651-2292
F: (510) 651-3076
Atwood Mobile Products
3196 Thompson Rd.
Fenton, MI 48430
T: (810) 629-9558
F: (810) 629-8031
Trident Consolidated Industries Inc.
19430 E. San Jose Ave.
City of Industry, CA 91748
T: (909) 594-0235
F: (909) 595-6025
VVP America
Binswanger Mirror Co.
Highway 8 East
P.O. Box 1400
Grenada, MS 38902-1400
T: (601) 226-5551
F: (601) 226-9787
Viracon Inc.
800 Park Drive
Owatonna, MN 55060
T: (507) 451-9555
F: (507) 444-3555
Int’l F: (507) 451-2187
e-mail: glass@viracon.com
Vitrerie April
12755 Boul Industriel
Montreal Quebec H1A4Z6
T: (514) 640-5355
F: (514) 640-5357
Wescan Glass Industries Inc.
101 Rosetown Ave.
Penticton, British Columbia
V2A 3J3 Canada
T: (250) 493-8111
F: (250) 493-5575
Windshield Installation Network
1120 Magee St.
Elmira, NY 14901
T: (607) 734-4009
F: (607) 734-4519
