Hydraulic Elevators

Otis Hydraulic Series systems provide solutions for low-rise applications. A wide range of architectural and control options provide exceptional value. Standard installation methods enable Otis crews to expedite installation with attention to quality and performance standards.

Holed Hydraulic

Otis Holed systems provide safe, reliable and consistent operation. In addition, options such as our “Solid-State Starter” help provide precise control with reduced demands on the building’s electrical system. And Otis' double-bottom cylinder with sealed polyvinyl chloride (PVC) protection lowers the risk of soil and ground-water contamination.

Double-bottom cylinder with sealed PVC protection

Otis Holed Hydraulic systems incorporate sealed PVC protection, which diminishes the chance of damage caused by corrosion. Constructed of durable, non-corrosible material, it surrounds the wall and bottom of the in-ground cylinder and is sealed at the cylinder head. Otis' sealed PVC protection offers significant benefits. It provides a means to monitor the space between the cylinder wall and the PVC. In addition, its evacuation port enables the removal of unwanted liquids that may collect in the space between the PVC protection and the cylinder.
