Artists have turned to glass for its intrinsic beauty for centuries. Now, with AGC Patterned Glass, architects, designers and builders are offered the same freedom to create translucent works of art for a myriad of applications.
Frequently chosen for its decorative value alone, patterned glass has the unique capacity to separate space while sharing light. Whether it is "one of a kind" treatment for a foyer or doorway, or the central focus of a shower or tub enclosure, the smart alternative is our patterned glass.
Choose from a large variety - all with the unique ability to separate space while sharing light. AGC also has the capability to develop and produce new or custom patterns as required by our customers. Whether it is a classic look or a new, contemporary design, AGC offers a variety of glass to meet your needs.
Patterned Glass by AGC is available in varying degrees of obscurity or diffusion and different thicknesses.
Applications:
- Shower doors and tub enclosures
- Patio furniture
- Interior partitions
- Translucent door treatments
- Decorative furniture
- Palladium windows
- Lighting fixtures
- Foyers and vestibules
|
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 1/8" |
Yes |
No |
60 x 84 |
| 5/32" |
Yes |
No |
60 x 132 |
| 3/16" |
Yes |
No |
60 x 132 |
| |
|
|
|
| |
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 5/32" |
Yes |
No |
60 x 132 |
| 3/16" |
Yes |
No |
60 x 132 |
| |
|
|
|
| |
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 5/32" |
Yes |
No |
60 x 132 |
| |
|
|
|
|
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 5/32" |
Yes |
No |
60 x 132 |
| |
|
|
|
|
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 5/32" |
Yes |
No |
60 x 132 |
| 3/16" |
Yes |
No |
60 x 132 |
| |
|
|
|
|
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 3/16" |
Yes |
No |
56 x 84 |
| |
|
|
|
|
|
|
|
| Bathrooms are the perfect place for patterned glass. Providing varying degrees of privacy, AGC patterned glass is widely used in both windows and in tub and shower enclosures. |
| |
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| Single |
No |
Minimum
0.30 laminate |
48 x 60 |
| DS |
No |
Yes |
60 x 84 |
| 1/8" |
Yes |
No |
60 x 84 |
| 5/32" |
Yes |
No |
60 x 132 |
| 3/16" |
Yes |
No |
60 x 132 |
| |
|
|
|
|
|
|
|
| AGC Patterned Glass offers architects, designers and builders freedom to create translucent works of art for a myriad of applications. |
| |
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 5/32" |
Yes |
No |
60 x 132 |
| 3/16" |
Yes |
No |
60 x 132 |
| |
|
|
|
| |
|
|
|
| Frequently chosen for its decorative value alone, patterned glass can provide privacy while allowing light to create accents to a setting. |
| |
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 3/16" |
Yes |
No |
60 x 132 |
| |
|
|
|
| |
|
|
|
| For foyers and bathrooms, in board rooms and offices, the intrinsic beauty of patterned glass encourages its use in a myriad of applications. |
| |
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 1/8" |
Yes |
No |
60 x 84 |
| 5/32" |
Yes |
No |
60 x 132 |
| 3/16" |
Yes |
No |
60 x 132 |
| |
|
|
|
|
|
|
|
| AGC patterned glass offers form with function. These durable textures allow designers and manufacturers to utilize glass even in household items. |
| |
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 3/16" |
Yes |
No |
52 x 66 |
| |
|
|
|
|
|
|
|
Rugged, durable...that is AGC Lighting Glass. This amazing low-iron glass product offers maximum light transmission with minimum absorption but can be used for any number of applications--just like our other glass patterns. Abrasion-resistant and non-combustible, our glass is specially designed for commercial lighting applications.
Crystal 73™ lighting glass effectively blends transmitted light down to the work area. And, best of all, AGC glass doesn't "yellow" over time like plastic. Our lighting glass panels can also be tempered for added protection against thermal differences and mechanical stress. |
| |
|
|
|
| Thickness |
Temperable |
Lamination |
Max. Size |
| 5/32" |
Yes |
No |
48 x 102 |
| |
|
|
|
|
|
|
|
| AGC has developed a rolled patterned glass that has the look of more expensive art/antique style glass with the new Illusions™ pattern. This exciting new fire-polished texture with graceful, artistic design is now available for shipment. Illusions™ is perfect for virtually every application where normal clear glass and traditional patterned designs are used. The design creates a unique play on light while offering the slightest diffusion. From cabinets, to shower doors, to decorative glazing, Illusions™ is a patterned glass that offers subtle distinction. |
| |
|
|
|
| Applications |
|
|
|
- Kitchen Cabinets
- Shower Enclosures
- Partitions
- Patio Table Tops Illusions™
- Decorative Door Lites and Side-lites
- Transoms
- Furniture
|
| Thickness* |
Temperable |
Lamination |
Max. Size |
| 1/8" |
Yes |
Yes |
42 x 72 |
| 5/32" |
Yes |
Yes |
42 x 72 |
| 3/16" |
Yes |
Yes |
42 x 72 |
| |
|
|
|
| *Call your AGC Sales Representative or Sales Coordinator for possible availability of additional thicknesses. |
| |
|
|
|
|
|
|
|
| AGC has developed a new look for patterned glass. After extensive research and development, AGC’s patterned glass production facility has added a new design that offers both subtle obscurity and exceptional clarity. The first new product with this new appeal is named Glacier™ due to the pattern’s “ice-like" appearance. Unlike traditional matte or sandblast finishes of patterned glass products, the texture of the Glacier™ design has a “fire-polished" look. With Glacier™ the best of both worlds are achieved – obscurity that is desired, with the sparkle and diffusion normally seen in expensive cast glass products. |
| |
|
|
|
| Applications |
|
|
|
- Shower Enclosures
- Partitions
- Patio Furniture
- Shelving Glacier™
- Decorative Door Side-lites
- Transoms
- Cabinets
- Bathroom Windows
|
| Thickness* |
Temperable |
Lamination |
Max. Size |
| 1/8" |
Yes |
No |
60 x 132 |
| 5/32" |
Yes |
No |
60 x 132 |
| 3/16" |
Yes |
No |
60 x 132 |
| 1/4" |
Yes |
No |
60 x 132 |
| |
|
|
|
| *Call your AGC Sales Representative or Sales Coordinator for possible availability of additional thicknesses. | | | | | | | | | | | AGC is making available a patterned glass texture named Leaf™. Originally produced in limited quantities for furniture applications, this artistic new texture is now available to all markets without exclusivity limitations. The design is versatile enough to be glazed in all traditional patterned glass applications such as shower enclosures and partitions, but also can be used as a unique accent feature around an office, home or any other area where a new treatment of light and texture is desired. | | | | | | | Applications | | | | - Shower Doors
- Partitions
- Patio Furniture
- Shelving
- Decorative Door Side-lites
- Transoms
- Bathroom Windows
| | Thickness* | Temperable | Lamination | Max. Size | | 1/8" | Yes | No | 60 x 132 | | 5/32" | Yes | No | 60 x 132 | | 3/16" | Yes | No | 60 x 132 | | | | | | | *Call your AGC Sales Representative or Sales Coordinator for possible availability of additional thicknesses. | | |
Thickness | Max | Min | Target | Wt/Sq Ft | Temperable | Max. Size | 1/4" | 0.266 | 0.233 | 0.240 | 3.11 | Yes | 60 x 84 | 3/8" | 0.421 | 0.359 | 0.369 | 4.79 | Yes | 60 x 84 |
