US Tile909 Railroad Street Corona, CA 92882 Tel: 800-252-9548 Fax: 951-734-9591 Email: Mike.Vogel@ustile.com Website: http://www.ustile.com Affordable One-Piece S Roofing Tile The modern design of our one-piece S Mission Tile combines the cap and pan of a two-piece system into a single piece, delivering the same traditional aesthetics using fewer tiles, saving cost and installation time. Made from the same natural clays and kiln-fired colors, our Mission S Tile products are true to their roots, allowing custom roofscape options such as boosting, while maintaining the rich beauty and durability of clay at a substantially lower price.
One-Piece S TileWidth: 13” Length: 18” Pieces Per Square: 88 Approx. Weight Per Square: 800 lbs
Basic Use: US Tile clay roofing tiles are applied on sloped roofs where aesthetics, longevity and low life cycle costs are major considerations. Composition and Materials: US Tile products are manufactured from various clays and kiln-fired. US Tile products are available in standard earth tones and authentic kiln-flashed colors. Warranty: US Tile products are covered by US Tile’s Transferable Lifetime Warranty that includes coverage against fading and labor. Limitations: The standard roof pitch for US Tile Mission products is 3:12 (25%). Roof slopes below 3:12 (25%) require an approved waterproofing system. Standard US Tile Mission profile products are not recommended for climate zones that experience repeated freeze-thaw cycling. Grade 1 certified Mission profile products are available and meet the requirements of ASTM C 1167-96 and can be installed in areas with severe weather conditions. Installation Recommendations: Please refer to the Installation Manual for Moderate Climate Regions published by the Roof Tile Institute. Technical Data: US Tile Products – ICBO #3523. |
