Heavy Duty Gates and Turnstiles

Lawrence Heavy Duty Gates
Lawrence gates provide emergency exits, handicap accessibility and allow for passage of carts or bulk materials.These all-welded gates are designed for constant use. The patented closing mechanism (S.A.L. Gate U.S. patent No. 5133152) insures a gentle return suitable for handicap access. Comes complete with gate support post and gate stop post. Posts are 36" high with welded 7" diameter floor flanges. In addition, anchor pipes are recommended for maximum strength. Center to center of post measurement is 3'6" resulting in a 3'0" wide clear opening. Shipping weight is approximately 50 lbs.
Please provide sketch when ordering – contact us for details.

Standard, Self Closing Gate
SAL-1-2P
Polished brass
SAL-1-3S
Satin stainless steel
SAL-1-3P
Polished stainless steel.

Round Corner, Self Closing Gate
Model SAL-2-2P
Polished brass
Model SAL-2-3S
Satin stainless steel
Model SAL-2-3P
Polished stainless steel

Manually Closing Gate
With latch to accept lock.
Model SAL-3-2P
Polished brass
Model SAL-3-3S
Satin stainless steel
Model SAL-3-3P
Polished stainless steel

Electric Access Gate
Operates on 115 VAC. Complete with power supply and control button.
Model SAL-5-2P
Polished brass
Model SAL-5-3S
Satin stainless steel
Model SAL-5-3P
Polished stainless steel

Custom Gates
Our custom fabrication department is capable of bringing your ideas to life. Please submit accurate drawings for an estimate.

ADA & UFAS COMPLIANCE.
All Lawrence Heavy Duty Gates comply with ADA/UFAS 4.4.1 regarding protruding objects.

Turnstiles

Where positive control of traffic
flow in one direction is needed, turnstiles, combined with the appropriate railing, provide the best solution. Space considerations determine whether 4-arm or space-saving, floor or wall mounted, fixed or portable units are required. These precision engineered turnstiles allow you to choose the correct match for your facility as well as answer the need for registering, if desired.

Space-Saving Turnstiles Registering and Non-Registering
Three arm turnstiles, designed to meet minimum space requirements, are one-way traffic controllers with self positioning arms. All models, except portable, mount to the floor through holes in the base.

When ordering specify rotation left hand, right hand

Model 105-3S Stainless steel arms and housing, wear-resistant black vinyl painted pedestal. Non-registering. Overall width from back to tip of arm: 23"; Weight: 90 lbs.
Model 105-2P Same as 105-3S but with brass arms and housing.
For Model 105-3S and Model 105-2P:
To include Counter/Register, add -R.
For portable unit with Floor Tread and Guide Rail, add -GR. Overall width: 24"; Weight: 120 lbs.

Model 88 4-Arm Turnstile
For Use with Model 2L7-T Railing Assembly. One-way, non-registering traffic controllers with pedestal secured to the floor by means of bolts or lag screws through holes in base flange. Quiet, featherweight non-spinning action. Chrome-plated with deep arms. Height: 35"; spread of arms: 38"; shipping weight: 70 lbs. Normally supplied with counter clockwise rotation unless clockwise is specified.

When ordering specify rotation Counter Clockwise, Clockwise

  1. A number of optional floor securements are offered. We recommend Model 1225. 4 required per turnstile.
  2. Adapta-Rail is the system most used with turnstiles.
  3. Many situations call for gates to complete a traffic flow solution. Contact us for our gates and typical turnstile and gate layouts.
Model 98 Turnstile All polished chrome. Complete with post and 7" diameter floor flange. Non-registering.
Overall width: 27"; Weight: 50 lbs.
Model TY-7 Yoke Polished chrome. For maximum security with Model 98 Turnstile. Complete with post and 7" diameter floor flange.
Model 99 These non-registering or registering (Model 99-R) units are designed to integrate with our Adapta-Rail System. Comes with 2 posts and 7" diameter floor flanges. Overall width from back to tip of arms is 23";  Weight: 65 lbs.
Model 99-3S/1P Stainless Steel Arms, Stainless Steel and Black housing, Polished Chrome Posts.
Model 99-3S/3S Stainless Steel Arms, Stainless Steel and Black Housing, Stainless Steel Posts.
Model 99-2P/2P Brass Arms, Brass and Black Housing, Polished Brass Posts.
Model 104 Wall mounted version of our Model 99 turnstile, complete with mounting bracket. Back measures 6" x 17", width from back to tip of arms is 23". Weight with bracket is 50 lbs.
Model 104-3S Stainless Steel Arms, Stainless Steel and Black Housing.
Model 104-2P Brass Arms, Brass and Black Housing.
Add -R to above models to include Counter/Register.

Model 2L7-T Railing Assembly
When ordering, please supply a simple sketch showing the direction of traffic flow and position of railing assembly in relation to adjacent railing.
Required with the turnstile to insure one way traffic. Shown and priced with 7" diameter floor flanges. Other floor securements to match adjacent railing supplied and priced as required.
Model 2L7-T-1P Polished chrome
Model 2L7-T-3S Satin stainless steel
Model 2L7-T-2P Polished brass

Model SK-7 Railing Assembly
Model SK-7
Polished chrome, polished brass or stainless steel.12" wide, 34" high, 30" long. Turnstiles ordered separately.

Railing Opposite Turnstile
Section of railing (minimum 2 feet) opposite turnstile and parallel to flow of traffic insures proper function. This railing can be ordered as Adapta-Rail.
