X-TREME^™ – Concrete Slab Vapor Barrier

X-TREME^™ is the new commercial and industrial construction vapor barrier that meets ASTM E-1745 Class A, B and C requirements. X-TREME^™ is the latest addition to the Tex-Trude family of quality products.

A true high performance vapor barrier, the X-TREME^™ products are composed of a new generation polyolefin/ polyethylene resins that enable it to guard against damage, molds, VOC glue failures, radon and methane gas.

Available in 10, 15 and 20 mil thicknesses, this high puncture resistance vapor barrier is engineered to withstand even the roughest of construction jobsite conditions and building traffic.

X-TREME^™ is backed with Tex-Trude's commitment to providing the highest quality product at a competitive price.

Using the latest technology, X-TREME^™ is designed for use under concrete slabs to protect against moisture migration, to control radon and many other soil contaminates. It is important to follow proper installation instructions in order for X-TREME^™ to reach its full potential.

• Controls radon and methane gas
• Protects against damage, molds and VOC glue failures
• Lowers utility bills
• Enables project requirements to be estimated easily
• Allows for trouble-free handling in the field
• Installs quickly and smoothly with few seams

• X-TREME^™ 10 mil is available in 14' wide rolls by 200' long. (2,800 ft²)
• X-TREME^™ 15 mil is available in 14' wide rolls by 150' long. (2,100 ft²)
• X-TREME^™ 20 mil is available in 12' wide rolls by 150' long. (1,800 ft²)
• Custom sizes are available upon request.

X-TREME^™ is manufactured blue in color.

American Society for Testing & Materials (ASTM)

• ASTM E 1745 – Standard Specification for Water Vapor Retarders Used in Contact with Soil or Granular Fill Under Concrete Slabs
• ASTM D 882 – Test Methods for Tensile Properties of Thin Plastic Sheeting
• ASTM D 1709 – Test Methods for Impact Resistance of Plastic Film by Free-Falling Dart Method
• ASTM E 96 – Test Methods for Water Vapor Transmission of Materials
• ASTM E 154 – Test Methods for Water Vapor Retarders Used in Contact with Earth under Concrete Slabs, on Walls, or as Ground Cover
• ASTM F 1249 – Test Method for Water Vapor Transmission Rate Through Plastic Film and Sheeting Using a Modulated Infrared Sensor
• ASTM E 1643 – Standard Practice for Installation of Water Vapor Retarders Used in Contact with Earth or Granular Fill Under Concrete Slabs

American Concrete Institute (ACI)

• ACI 302.1R-96 Minimum Thickness (10-mil)

Please contact Tex-Trude directly for pricing and availability.

Tex-Trude warrants this product to meet the published specifications and to be free of defects in workmanship and materials at the time of shipment from our factory. If any X-TREME^™ materials prove to contain manufacturing defects that substantially affect the performance, then Tex-Trude will at their option replace the materials or refund the purchase price. THIS LIMITED WARRANTY IS THE ONLY WARRANTY OFFERED BY TEX-TRUDE, LP AS IT RELATES TO X-TREME^™ PRODUCTS. THERE ARE NO OTHER WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEX-TRUDE SPECIFICALLY DISCLAIMS LIABILITY FOR ANY INCIDENTAL, CONSEQUENTIAL, OR OTHER DAMAGES.

A physical inspection of the area designated for X-TREME^™ must be performed prior to the installation. The surface must be prepared in accordance with the industry standard and/or architectural specifications. X-TREME^™ 10 mil, 15 mil and 20 mil must be installed as defined in ASTM E-1643 (the procedure for the installation of a water vapor retarder used in contact with the earth or granular fill under concrete slabs). X-TREME^™ should be installed over tamped earth, sand, or aggregate base by unrolling and completely covering area to receive building slab or other specified area.

The seams must be overlapped a minimum of six (6) inches and sealed with X-TREME^™ Sealing Tape or it must be heat welded. All exposed penetrations must be sealed using the X-TREME^™ Sealing Tape per the manufacturer's recommendations.

None Required

Tex-Trude is available to provide site or project specific details or recommendations upon request.

X-TREME^™ brochures are available from X-TREME^™ distributors, X-TREME^™ sales representatives and at www.tex-trude.com.
