Specified Technologies, Inc. -CS Composite Sheet

DOWNLOADS

SpecSeal Composite Sheet is the ideal solution for large openings where a permanent seal is required. Composite sheet consists of a thin sheet steel with intumescent embedded onto a single side.


Category: fire stopping | firestopping | firestopping panels...

MasterFormat: Firestopping | Penetration Firestopping


View Product Details From Manufacturer


Specified Technologies, Inc.
210 Evans Way
Somerville, NJ 08876
Tel: (800) 992-1180
Fax: (908) 526-9623

customerservice@stifirestop.com

https://www.stifirestop.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


CS Composite Sheet

SpecSeal Composite Sheet is the ideal solution for large openings where a permanent seal is required. Composite sheet consists of a thin sheet steel with intumescent embedded onto a single side. Composite sheet partners with other SpecSeal firestop products such as Firestop Collars and EZ Path Devices to size down oversized openings.

Features

  • Profession Fit and Finish
  • Partners with other SpecSeal Firestop Products
  • Easily cut with hand sheers
  • Tested for up to 4 Hours of fire resistance when tested to ASTM E814/UL1479


See More


Specifications

Physical Properties
PropertyValue
Nominal Thickness0.1 in (2.5 mm)
Nominal Weight1.4 lb/sq ft (6.9 kg/sq m) Intumescent
Expansion Begins350°F (177°C)
Volume Expansion15x (typical free expansion)
In Service Temperature-10°F (-23°C) - 130°F (54°C)
Storage TemperatureLess than 130°F (54°C)
Radiation ExposureUnaffected
STC Rating55 (Relates to specific construction) (ASTM E 90-04)
VOC ContentN/A
Shelf LifeNo Limit
Ordering Information
Catalog NumberUPC NumberDescription
CS162873057311628916" x 28" (41 cm x 71 cm)
CS243673057312436924" x 36" (61 cm x 92 cm)
CS363673057314136636" x 36" (92 cm x 92 cm)
CS364173057313641636" x 41" (92 cm x 104 cm)
CS285273057313636228" x 52" (71 cm x 132 cm)
