ADA Compliant Railing

ADA Handicap Accessibility Railings for Ramps and Stairs

This ADA compliant railing add on is perfect for interior or exterior applications! Our systems usually require no welding or on-site machining. These ADA handicap railings are designed around a universal set of patented fittings. Atlantis Rail ADA handicap accessibility railings are available in highly polished or brushed finish stainless steel rails. We ship them ready to install in the field.

The versatility of our ADA compliant railing allow Atlantis Rail to provide compliant handicap accessibility with most of our guard rail systems. We can provide ADA options for any SunRail, RailEasy or Spectrum system. The patented, modular components allow for the accurate production of ADA railings for any size project. Your choice of a brushed or highly polished stainless steel finish is available. Let Atlantis Rail provide you with a cost effective and easy option for ADA compliant accessibility solutions.

SPECIFICATIONS

Ramp Sections
The ADA Compliant System is offered in a standard height of 42″ with a handrail height of 36″. It consists of a stainless steel top rail, posts, upper handrail and lower bump rail with horizontal cable infill.

Note: Railing heights are offered in these dimensions due to nationwide building codes. However, Atlantis Rail can supply custom heights/lengths upon request.

Between Posts Length
Atlantis Rail recommends staying within 4′ section lengths to maintain structural integrity.

Railing Finish
The ADA Compliant System is offered in a highly polished or brushed finish.

Infill Options
Atlantis Rail Systems offers standard infill options of cable railing, balusters and glass panels.

OPTIONS

Add Micro Star™ LED Lighting underneath the stainless steel top rail to illuminate the architectural features of the cable railing system. We invite you to visit our Rail & Deck Lighting page to view our complete line of LED lighting options.
